SwellPro Splashdrone 4

SwellPro Splashdrone 4

Multi-functional waterproof flight platform.

Specifications:

Aircraft
Waterproof Rating:IP67
Drone Weight (include battery and propellers):2.18 kg
Axis Diameter:450 mm
Max Ascend Speed:4m/s
Max Descend Speed:4m/s
Max Flight Speed:22 m/s (ATTI)); 10 m/s (GPS)
Max Tilt Angle:12.5° (ATTI); 25° (ATTI fast)
Max Takeoff Altitude:120m (GPS) / ATTI - no limitation
Max Wind Speed Resistance:8 m/s (11-16knots)(F4); 14 m/s (F7) peak gust
Max Flight Time:30 mins (no wind & no load) (approx. 25 mins with GC3-S, approx.15 mins with load of 1.5kg)
Max Flight Distance:5.0 km
Max Payload Capacity:2.0 kg
Propellers:#1242 carbon fiber quick release propellers
Operating Frequency:5180 - 5875 MHz
Transmitter Power (EIRP):FCC/IC: ≤ 24 dBm CE/SRRC/MIC: ≤ 20 dBm
Working Temperature:-10℃ ~ 40℃
Satellite Positioning Systems:GPS/GLONASS
Hovering Precision:±0.5 m (vertical); ±0.5 m (horizontal)
Pass-through Serial Port:Connect to a third-party device and transfer the data of the third-party device to the remote control
UART:Allows for TTL serial port to TCP, support baud rate of 115200
Wi-Fi Hotspot:IP: 192.168.1.101:2222
Power Input:12V/2A | 5V/2A

Remote Control
Waterproof Rating:IP66
Operating Frequency:5180 - 5875 MHz
Transmitter Power (EIRP):FCC/IC: ≤ 24 dBm CE/SRRC/MIC: ≤ 20 dBm
Real-time Video Transmission:720P@30fps
Latency:200 ms (It depends on the actual shooting environment and mobile devices)
Battery:2S 3600mAh
Working Time:7 hours
Working Current/Voltage:0.3A/7.4V
Ethernet Port:IP: 192.168.2.220:2222
Wi-Fi Hotspot:IP: 192.168.2.220: 2020; Default password: 12345678
Mobile Device Mount:Suitable for any size phones; Tablets require a larger mount (sold separately)
Screen:2.68 inch, 128x64
Working Temperature:-10℃ - 40℃
Remote Charging time:3 hours
Power Input:5V/2A

Intelligent Battery
Nominal Capacity:6600mAh
Voltage:14.8V
Type:Intelligent 4S LiPo
Watt Hours:97.68 Wh
Size:153.6*82.4*48.3mm
Weight:735 g (±5 g)
Working Temperature:-10℃ - 40℃
Charging Time:1.5 hour
Max Charging Power:84 W

Charger
Input:100 – 240V, 50/60Hz
Output:16.8V@Dynamic Current / 5V@1.5A
Rated Power:84.5 W
Mobile Device connection
Operation Frequency:5180 - 5875 MHz
Max Transmission Distance:10 m (Unobstructed, free of interference)

APP
Mobile App Name:SDFly
Live View Quality:720p@30fps
Latency:＜ 250 ms (depending on environmental conditions and mobile devices)

x1                                                    x1

Power Adapter                              Power Cable

x1                                                         x1

RC Barrel Power Cable                  Micro USB Cable

x1                                                          x1

Hex Screwdriver x2 Hex Screw    Barometric Vent(extra)

x1                                                                x1

-Manual -Certificate -Maintenance   Case
